BARS X - SPRİNG HARVESTER

The BARS X spring harvester is used for breaking up soil clods, soil mixing and pre-sowing preparation. Thanks to the spring-independent disc design and engineering design, each disc operates separately from each other thanks to an independent bearing. Thanks to the springs in each disc, breakdowns and damage that may occur to the chassis are eliminated by moving the discs back and forth when the equipment gets stuck due to obstacles. It is less affected by the surface. During tillage, it breaks up weeds and plant residues in the soil and mixes them with the soil. This model consumes less traction power and energy.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

BARS X - SPRİNG HARVESTER

BARS X 16

BARS X 24

BARS X 30

BARS X 34

BARS X 16(with roller)

BARS X 24(with roller)

BARS X 30 (withroller)

BARS X 34(with roller)

Number of disks

pcs

16

24

30

34

16

24

30

34

Working width

mm

2000

3000

3750

4250

2000

3000

3750

4250

Working depth

mm

250

250

250

250

250

250

250

250

Weight

kg

930

1360

1640

1870

1200

1715

2020

2235

Tractor power

hp

55-65

95-110

130-140

150-170

55-65

95-110

130-140

150-170
