ASTRA T – TELESCOPIC DISC TYPE PNEUMATIC SEEDER

ASTRA T – TELESCOPIC DISC TYPE PNEUMATIC SEEDER

The ASTRA T telescopic disc type pneumatic seeder – designed for sowing seeds of treated and semi-treated soils. In sowing units, the seed bed is opened using 2 discs made of special material, ensuring accurate sowing of all types of seeds with the required seeding range and row spacing. Thanks to rubber wheels located on both sides of the sowing units, it is possible to apply seeds and fertilizers to the same depth. The seeds are compressed by V-shaped pressing wheels located behind the seeder. The robust design of the seeder, ease of use and flexibility of operation ensures high efficiency and saves time.

This model has a hydraulic telescopic frame that allows you to adjust the distance between rows 45,50,55,60,65 and 70 cm and change the road and working position without much effort for safe transportation on roads.  This model is available in 4, 6, 8 or more rows upon customer request.

Standard model kit:

Hydraulic marker

Reflective stickers

Mixer for fertilizer

Cardan shaft

Axe type fertilizer units.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

ASTRA T – TELESCOPIC DISC TYPE PNEUMATIC SEEDER

Astra T6F

Astra T6

Row

pcs

6

Fertilizer system



Fertilizer

Without fertilizer

Width

mm

4000

4000

Heigth

mm

1600

1600

Length

mm

2300

2300

Seed tank Volume

lt

6x35

6x35

Fertilizer Tank Volume

lt

2x200

-

Disc Hole Diameter

mm

1-6

1-6

Disc Number of Holes

pcs

Variable

Variable

Distance Between Rows

cm

45-50-55-60-65-70

45-50-55-60-65-70

Distance Row

cm

1-177

1-177

Working Speed

km/h

6-8

6-8

Required Power

hp

90-110

90-110

Weight

kg

1450

1250
