ASTRA TDP - TELESCOPIC DISC TYPE PNEUMATIC SEEDER- DEEP PLANT

ASTRA TDP - TELESCOPIC DISC TYPE PNEUMATIC SEEDER- DEEP PLANT

The ASTRA TDP telescopıc disc type pneumatic seeder-deep plant - designed for sowing seeds in treated and semi-treated soils. In sowing units, the seed bed is opened using 2 discs made of special material, ensuring accurate sowing of all types of seeds with the required seeding range and row spacing. Thanks to rubber wheels located on both sides of the sowing units, it is possible to apply seeds and fertilizers to the same depth. The seeds are compressed by V-shaped pressing wheels located behind the seeder. The robust design of the seeder, ease of use and flexibility of operation ensures high efficiency and saves time.

This model has a hydraulic telescopic frame that allows you to adjust the distance between rows of 45,50,55,60,65 and 70 cm and without much effort change the road and working position for safe transportation on roads and has a special coulter design that ensures deep penetration into the soil. This model is available in 4, 6, 8 or more rows upon customer request.

Standard model kit:

Hydraulic marker

Hydraulic marker

Reflective stickers

Mixer for fertilizer

Cardan shaft

Axe type fertilizer units/

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

UNIT

ASTRA TDP - TELESCOPIC DISC TYPE PNEUMATIC SEEDER-DEEP PLANT

Astra TDP6F

Astra TDP6

Row

pcs

6

Fertilizer system



With fertilizer

Without fertilizer

Width

mm

4000

4000

Heigth

mm

1600

1500

Length

mm

2300

2300

Seed tank Volume

lt

6x35

6x35

Fertilizer Tank Volume

lt

2x200

-

Disc Hole Diameter

mm

1-6

1-6

Disc Number of Holes

pcs

Variable

Variable

Distance Between Rows

cm

45-50-55-60-65-70

45-50-55-60-65-70

Distance Row

cm

1-177

1-177

Working Speed

km/h

6-8

6-8

Required Power

hp

90-110

90-110

Weight

kg

1450

1250
